Centrifugal casting is the art inherited by memory, senses and experience
The innovation is from the brainstorm between older and newer generations
The great centrifugal casting is created by your trust and our expertise
Materials of large tubes ( centrifugal casting ):
- 300 series stainless steel
- 400 series stainless steel
- Duplex stainless steel
- 17-4PH stainless steel
- Ni-resist
- Nickel-based alloys
- Heat-resistant alloys
Dimensions of large tubes ( centrifugal castingc):
- Diameter: 50~400 mm
- Based on the molds
Centrifugal casting is very suitable for producing large tubes. Most customers need large tubes which are seamless and with the good mechanical properties are for special projects. The diameter of the large tube are customized instead of the specification usually. Once selecting the proper mold and controlling the manufacturing parameters well, the perfect large tubes will be formed. You’ll save machining and material costs. If you have the demands of large tubes made at LAWAI, made in Taiwan, please contact us via the left inquiry form or email.
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
CF8 | A351/743/744 CF8 | J92600 | 304 | S30400 |
CF3 | A351/743/744 CF3 | J92500/J92700 | 304L | S30403 |
CF8M | A351/743/744 CF8M | J92900 | 316 | S31600 |
CF10SMnN (Nitronic 60) | A351/743/744 | J92972 | ||
CG6MMN (Nitronic 50) | A351/743/744 | J93790 | ||
CF3M | A351/743/744 CF3M | J92800 | 316L | S31603 |
CF3M-HM (Min. 2.75% Mo) | ||||
CH20 | A351/743 | J93402 | 309 | S30900 |
CE20N | A351/451 | J92802 | ||
Nitronic 33 | ||||
Nitronic 40 | ||||
CN7MS | A744 | J94650 | ||
CN3MN | A743/744 | J94651 | ||
CK3MCuN | J93254 | 254SMO |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
CD4MCu | A 351 /A 890 | J93370 | 1 A | |
CD3MN | A890/A995 4A CD3MN | J92205 | 2205 (4A) | S31803 |
CD7MCuN | A890 1C CD3MCuN | J93373 | S32550 | |
CD4MCuN | A890/A995 1B CD4MCuN | J93372 | 1 B | |
CE3MN | A890/A995 5A CE3MN | J93404 | 2507 | S32750 |
CE8MN | A890/A995 2A CE8MN | J93345 | Escoloy (2A) | |
CD3MWCuN | A890/A995 6A CD3MWCuN | J93380 | Zeron 100 (6A) | S32760 |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
718 | N07718 | INCONEL 718 | N07718 | |
800H | A351 CT15C | N08151 | INCOLOY 800H | N08810 |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
CB7Cu-1 | A747 Gr CB7Cu-1 | J92180 | 17-4PH | S17400 |
CB7Cu-2 | A747 Gr CB7Cu-2 | J92110 | 15-5PH | S15500 |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
Ni-resist 1 | A436 Type 1 | F41000 | ||
Ni-resist 2 | A436 Type 2 | F41002 | ||
D-2M (DIN GGG-NiMn 23 4) |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS |
