LAWAI INDUSTRIAL CORPORATION is the centrifugal casting foundry in Taiwan.
Stainless steel sleeves (shaft sleeves / wear sleeves ) produced by centrifugal casting technique are the popular products at LAWAI because the centrifugally cast sleeves are with fine grain structure and almost zero pore easy to be machined. Customers save much machining cost once we provide them the stainless steel sleeves ( shaft sleeves / wear sleeves) with the exact dimensions.
Our stainless steel sleeves ( shaft sleeves / wear sleeves) are used in various applications such as pump, oil & gas, chemical, marine industries …etc.
Our stainless steel sleeves (shaft sleeves / wear sleeves) are supplied to pump manufacturers mainly especially jet pumps (centrifugal pumps) manufacturers for watercraft market ( For example, jet ski)
The materials of stainless steel sleeves ( shaft sleeves / wear sleeves) are as follows.
- Stainless steel 300 series including 304, 316…etc
- Stainless steel 400 series including 410, 420… etc
- PH steel including 17-4PH
- Duplex stainless steel including 2205, 2507
The dimensions of stainless steel sleeves ( shaft sleeves / wear sleeves) we produce:
OD > 50 mm
If you have the demands of rough machined stainless steel sleeves (shaft sleeves / wear sleeves) manufactured by centrifugal casting, we believe LAWAI’s Taiwan quality centrifugally cast sleeves will be your ideal materials!
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
CF8 | A351/743/744 CF8 | J92600 | 304 | S30400 |
CF8M | A351/743/744 CF8M | J92900 | 316 | S31600 |
CF3M | A351/743/744 CF3M | J92800 | 316L | S31603 |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
CA15 | A743 CA15 / DIN 1.4008 | J91150 | 410 | |
CA40 | A743 CA40 / DIN 1.4027 | J91153 | 420 | |
CA6NM | A743 CA6NM / DIN 1.4313 | J91540 | 13-4, F6NM | |
CA40F | A744 CA40F | J91154 | 420F | |
416 | A582 416 | 416 | S41600 |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
CB7Cu-1 | A747 Gr CB7Cu-1 | J92180 | 17-4PH | S17400 |
LAWAI ALLOY | Cast Specifications | Wrought Specifications | ||
---|---|---|---|---|
ASTM | UNS | AISI | UNS | |
CD3MN | A890/1995 CD3MN | J92205 | 2205 | S31803 |
CE3MN | A890/A995 CE3MN | J93404 | 2507 | S32750 |
